Vacuum Pump Cabinet
Design Considerations

Vacuum pumps suck, and that suction power can produce significant heat! When a pump is trapped in an enclosed and acoustically-insulated vacuum pump cabinet, the air temperature can quickly rise beyond the operating range of the pump. This common oversight can be quite frustrating upon completion of the lab project. The users move in and their vacuum pumps immediately begin to overheat. To protect the pumps, they leave the pump cabinet doors open, or the pumps are pulled out and put on the floor until the problem can be resolved.

How can we avoid this? Vacuum pump cabinets are designed for basic smaller pumps but can be configured for larger pumps or even multiple smaller pump units. A bit of simple design preplanning on vacuum pump cabinets is essential to a successful project. And it’s not just the heat output that is important; it’s the noise level, the weight
